Data

• How should large datasets be handled?
  • Pagination
    • What type of controls should be supported?
      • Back, next, select page, go to first or last, jump to page menu, page buttons…
    • Should the user be able to define how many records are shown per page?
      • Should this setting be restored when the application is reloaded?
      • Should this be a view-level setting or an application-level setting?
  • Virtual scroll (data is dynamically loaded and removed as the user scrolls through the content)
  • Infinite scroll or lazy loading (more data is loaded as the user reaches the bottom)
  • Showing dynamic messaging to encourage the user to filter the data more aggressively.
• How should empty states be handled?
  • Should the display be different based on the reason there is no data?
    • No data has ever existed
    • No data exists currently
    • No data was returned with the current filter(s) or search
    • No data was returned due to an error
• Should the display of data change for specific users or roles?
  • e.g., An admin role may have different graphs or summaries compared to a basic user.
• Should the table allow filtering the data?
  • Is the filter column-specific or applied to the entire table?
  • Should all columns be filterable?
  • Can more than one column be filtered at the same time?
  • Are there any possible data points that the user cannot filter by?
  • Can the table be filtered on a global level as well?
  • How should the search be executed?
    • Explicit match
    • Fuzzy match
    • Do any phrases or terms get extra weight? (industry terms, trends, location..)
    • How should typos be handled?
    • How should synonyms be handled?
    • Should search operators be supported? (this +that -notThis…)
    • Should wildcards be supported?
    • Should regex be supported?
    • Is the search executed in real time or should the user be required to submit the query?
  • Should multi-level filters be supported? (i.e. 'rule-builder')
  • Should query results highlighted?
    • Should it be highlighted at the row level, cell level or both?
• Can the user search for specific data?
  • Note: We consider it a 'search' when the query requests data from the server and a 'filter' when the query narrows a data-set.
  • Note: See the section above 'Should the table allow filtering the data?' as most of the questions also apply here.
• How should the data initially be sorted when the table first loads?
• If data is updated while the user is viewing the table, how should the user be alerted?

Rows

• Should rows support custom styles?
  • Status, validity, selection, highlight…
• Should rows support pinning?
  • Where can they be pinned?
    • Top, content, bottom
  • How many rows can be pinned at once?
    • A single top, content or bottom
    • A single top and a single footer
    • Multiple top and/or multiple bottom
    • Multiple top, content or bottom
• Should the header row be fixed or scroll out of view?
• Can rows be grouped?
• Should rows support varying heights?
  • How should row content be vertically aligned?
• Should rows support custom templates?
• Should rows support dynamic height changes?
  • Expansion panel, progressive enhancement..
• Can a row be in a selected state?
  • Do any data types have restrictions on when a user may or may not select or unselect a row?
  • Are selections removed or preserved when the user paginates after selecting one or more rows?
  • How should the selected state be visually represented?
• Will any views need a summary row?
  • Will there be a need for more than one summary row?
  • Will any of the summary rows require data not included in the tables primary data set?
• Should the table support a common set of actions for a row? (delete, duplicate..)
  • Should these actions always be visible?
    • Always visible
    • Shown on hover or focus
    • Table enters 'edit' mode
• Should rows support a disabled or read-only state?
• Is there a need to highlight certain rows?
  • Is there a single highlight style or multiple types?
  • Can multiple rows be highlighted at the same time?
• Should users be able to quickly view more detail?
  • Popover, modal, drawer, expansion panel, split view..
  • Can multiple quick-views be open at the same time?
  • Do certain columns need to remain visible when the quick-view is open?
• Can data be edited at the row level?
• Should the table support zebra striped rows?
• Should a user be able to manually sort rows via drag and drop?

Columns

• Can columns be added or removed from the table?
  • How is the initial visibility determined for each column?
• Should columns support pinning?
  • Where can they be pinned?
    • Start, current location or end
  • How many can be pinned at once?
    • Only one start, content or end
    • One start and one end
    • Multiple start or multiple end
    • Multiple start, content or end
• Should columns support reordering?
  • Can column reordering be disabled for one or many columns?
• Can data be ordered by column data (sorting)?
  • Can a sorted column be 'unsorted'?
  • On the first sort, does the column sort ascending or descending?
    • Are there any data types that might require the opposite initial sort?
  • What visuals should be used to indicate the current order?
  • Can data be sorted by multiple columns at once?
    • How should column priority be indicated?
• Can columns be grouped?
• Can text alignment be customized for specific columns?
• How are columns initially sized?
  • Equal distribution (percentage)
  • Based on column contents (dynamic)
  • View level setting (fixed)
  • Weighted (a combination of percentage and dynamic)
  • How should sizing be affected when the data is wider than the viewport?
  • How should sizing be affected when the data is less than the width of the viewport?
• Should users be able to resize columns?
  • Should resizing be disabled for certain columns or views?
• Can a column be in a selected state?
  • Can multiple columns be selected?
    • Do the columns need to be contiguous?
• Should a column be able to span multiple columns?

Cells

• Should text wrap or be truncated when it is wider than the cell?
  • If truncated, how will users be able to see the full text?
    • Where should the text be truncated? (beginning, middle, end)
• Should cells support custom styles?
  • Background, typography treatment..
• Should cells support custom formatters?
• Should cells support full custom templates?
  • Content cells, header cells, footer cells or all cells?
• Should cells support inline editing?
  • How should the editor be presented?
    • Contenteditable, switch to input, popover, modal
  • How should the user determine when editing is possible?
  • How should state changes be represented? (i.e., updated, saved…)
  • What should happen if an edit fails?
    • Should the data revert to its previous state?
    • Should the field be marked as errored?
    • How should the user be alerted to the failure?
  • Should the user be able to undo or redo changes?
• Can a cell be in a selected state?
  • Can multiple cells be selected at once?
    • Do the cells need to be contiguous?
  • How is the selected state visually represented?
• Can a cell be in a disabled or read-only state?
• Is there a need to highlight certain cells?
  • Is there a single highlight style or multiple types? (e.g., positive, negative…)
  • Is there a need for multiple cells be highlighted at once?
• Should cells support any form of progressive disclosure?
  • Popover, modal, tooltip..
• What type of content should be supported?
  • Text, image, code, button, link, icon, number, data visualization, map, embed, dropdown, date-picker..

General

• Should the current state be restored if the page is refreshed?
  • State refers to sort, filter, column visibility, column order, column and row pinning, row selection, cell selection…
• Should the table support sharing or bookmarking a URL to a specific filtered or sorted state?
• Should the table support multiple display densities?
  • Is this setting per-view or application wide?
• What type of keyboard support should be supported?
  • This could range from simple arrow key support to full Excel-like keyboard controls.
• Should the table highlight the currently hovered row and/or column? (crosshair)
• Should the table support a custom context (right-click) menu?
• Should the table be responsive?
  • How should the table be displayed and function on small screens?
• Should touch devices be supported?
  • How should keyboard shortcuts be translated to touch devices?
  • How should batch selection work?
• Should the table support bulk actions?
• Should the table support a visual summary?
  • Which visualizations should be provided?
  • Can visualizations be customized?
    • Per view? Per user?
• Should the user be able to export the data?
  • What formats should be supported? CSV, PDF, Excel, clipboard..
  • What data should be exported?
    • The visible data.
    • All data in the current set regardless of current visibility.
• Should tables support nesting inside another table?
  • How many levels of nesting is needed?
• Should the table support a printer friendly view?
• Should the table support a high-contrast mode?

As always, I welcome any feedback, corrections, or suggestions on clarity. This is a document I personally continue to reference, and I hope it can help others as well!
